MHF® 4L

M.2 行業標準，組合高度最大為1.2 mm, 1.4 mm, 1.7 mm. 對應12 GHz 極佳的插入損耗和電壓駐波比

    對應12 GHz 的高性能小型連接器

    使用“i-Fit®” 技術的無焊料極細同軸線終端

    我們可提供MHF® 4L公座的各種線外徑及附加機械鎖扣供您選擇

*MHF® 4L 可與 MHF® 4 互配。
*關於機械鎖的額外嵌合保持力，請查看MHF® 4L LK插頭電纜組件。
*操作方法請參考「如何嵌合和解除」的影片來處理。
Mated Height:
1.2 max. 1.4 max. 1.7 max. (mm)
頻率範圍:
Up to 12 GHz
Micro-Coaxial Cable:
AWG 30 O.D. 1.37 mm AWG 33 O.D. 0.95 mm AWG 32 O.D. 1.13 mm AWG 36 O.D. 0.64 mm AWG 36 O.D. 0.81 mm

下載

對應12 GHz 的高性能小型連接器
電壓駐波比 插入損耗
MHF_4L_FAB1-1.jpg MHF_4L_FAB1-2.jpg



使用“i-Fit®” 技術的無焊料極細同軸線終端
FAB2_1.jpg FAB2_2.jpg FAB2_3.jpg
1. 中心导体
2. 绝缘体
3. 外层导体
4. 外被

5. 端子
6. 中心导体
7. 卷边



我們可提供MHF® 4L公座的各種線外徑及附加機械鎖扣供您選擇




 MHF_4L_Fab_3
Product name
MHF® 4L LK
MHF® 4L
MHF® 4L
MHF® 4L
Lock
With Lock
Without Lock
Without Lock
Without Lock
Mating Height
2.0 mm max.
1.7 mm max.
1.4 mm max.
1.2 mm max.
Coaxial O.D.
(Center Conductor AWG)
1.37 mm
(AWG 30)
●
●


1.13 mm
(AWG 32)


●

0.95 mm
(AWG 33)


●

0.81 mm
(AWG 36)



●
0.64 mm
(AWG 36)



●
Receptacle
MHF® 4 receptacle (20449-001E-**), MHF® 4L receptacle (20579-001E)



Product Type
Coaxial RF Connector
Mated Height
1.2 max. 1.4 max. 1.7 max. (mm)
SMT Size
2.0 x 2.0 mm
Frequency range Up to 12 GHz
Micro-Coaxial Cable
AWG 30 O.D. 1.37 mm AWG 33 O.D. 0.95 mm AWG 32 O.D. 1.13 mm AWG 36 O.D. 0.64 mm AWG 36 O.D. 0.81 mm
Shielded FPC / FFC
No
Applicable Standards (Reference Only)
5G sub6 IEEE802.11n IEEE802.11ac IEEE802.11ax IEEE802.11be Wi-Fi 4 Wi-Fi 5 Wi-Fi 6/6E Wi-Fi 7 LTE / LTE-Advanced LPWA Bluetooth GPS
Full EMI Shielding (ZenShield®)
No
Mechanical lock
No
VSWR (PLUG) DC~3GHz : 1.3 max. (O.D. 0.64, 0.81, 0.95, 1.13, 1.37 mm)
3GHz~6GHz : 1.45 max. (O.D. 0.64, 0.81, 0.95, 1.13 mm)
3GHz~6GHz : 1.4 max. (O.D. 1.37 mm)
6GHz~9GHz : 1.6 max. (O.D. 0.64, 0.81, 0.95, 1.13 mm)
6GHz~9GHz : 1.5 max. (O.D. 1.37 mm)
9GHz~12GHz : 1.9 max. (MHF 4L) (O.D. 0.64, 0.81, 0.95, 1.13 mm)
9GHz~12GHz : 1.6 max. (O.D. 1.37 mm)
VSWR (RECEPTACLE) DC~3GHz : 1.3 max. (O.D. 0.64, 0.81, 0.95, 1.13, 1.37 mm)
3GHz~6GHz : 1.4 max. (O.D. 0.64, 0.81, 0.95, 1.13, 1.37 mm)
6GHz~9GHz : 1.55 max. (MHF 4) (O.D. 0.64, 0.81, 0.95, 1.13, 1.37 mm)
6GHz~9GHz : 1.5 max. (MHF 4L) (O.D. 0.64, 0.81, 0.95, 1.13 mm)
9GHz~12GHz : 1.65 max. (MHF 4L) (O.D. 0.64, 0.81, 0.95, 1.13, 1.37 mm)

推薦料號

若清單中查詢不到您要找的料號，請使用調查表詢問。



MHF 4L RECOMMENDED PART NUMBERS

Part Number Description Part Number Weight (mg)
MHF 4L plug OD=0.81/0.64mm 20572-001R-08 20.2
MHF 4L plug OD=1.13/0.95mm 20565-001R-13 20.2
MHF 4L plug OD=1.37mm 20632-001R-37 33.2
MHF 4L receptacle 20579-001E 8.48



MHF 4L SAMPLE HARNESS FOR EVALUATION PART NUMBERS

MHF 4L

Part Number Description Part Number Weight (mg)
MHF 4L-4L harness OD=0.64mm L=50mm 8-25-0437 130
MHF 4L-4L harness OD=0.64mm L=100mm 8-25-0438 190
MHF 4L-4L harness OD=0.64mm L=200mm 8-25-0439 310
MHF 4L-4L harness OD=0.81mm L=50mm 8-25-0466 190
MHF 4L-4L harness OD=0.81mm L=100mm 8-25-0467 310
MHF 4L-4L harness OD=0.81mm L=200mm 8-21-0042 500
MHF 4L-4L harness OD=1.13mm L=50mm 8-23-0115 560
MHF 4L-4L harness OD=1.13mm L=100mm 8-23-0112 570
MHF 4L-4L harness OD=1.13mm L=200mm 8-21-0043 790
MHF 4L-4L harness OD=1.13mm L=500mm 8-24-0128 690
MHF 4L-4L harness OD=1.37mm L=50mm 8-23-0116 570
MHF 4L-4L harness OD=1.37mm L=100mm 8-23-0113 660
MHF 4L-4L harness OD=1.37mm L=200mm 8-23-0114 630
MHF 4L-4L harness OD=1.37mm L=500mm 8-24-0129 680


其他料號
請注意:此清單可能包含了暫時還沒有可用樣品的產品和不再銷售的型號。
如您有新的詢價，請參考上述推薦的料號。



MHF 4L OTHER PART NUMBERS

Part Number Description Part Number Weight (mg)
MHF 4 receptacle 20449-001E-03 4.54
MHF 4 receptacle thick plating type 20449-001E 4.54
MHF 4L plug OD=0.83mm 20565-001R-83 20.2
MHF 4L plug OD=0.81mm 20572-002R-08 20.2
SMA Adapters for MHF® Receptacles
RF_t7_ACC1.png RF_t7_ACC2.png RF_t7_ACC3.png RF_t7_ACC4.png  RF_t7_ACC5.png  RF_t7_ACC6.png
90449-002 90698-0001

90577-0100
90577-0200
90577-0350
90577-0750

 90576-0001 90684-0001 90683-0001



SMA Adapters for MHF® Plugs MHF® Accessories: Hand Tool
 RF_t6_ACC2.jpg RF_t6_ACC3.png  RF_t8_ACC1.png  RF_t8_ACC4.png
90194-001 90449-003-01 90609-0001(**)
90873-0001(***)		 90616-0008
90615-0013



MHF 4L ACCESSORIES PART NUMBERS

Part Number Description Part Number Weight (mg)
MHF 4/4L/4L LK SMA adapter for plug electrical-performance-check 90449-001 2571.2
MHF 4/4L/4L LK SMA adapter for plug voltage-check 90449-003-01 680
MHF 4/4L/4L LK SMA adapter for receptacle electrical-performance-check 90449-002 1685
MHF 4/4L/4L LK SMA adapter for receptacle high-cycle 90698-0001 7170
MHF series SMA adapter for receptacle high-cycle narrow-pitch wire L=100mm 90577-0100 4503.2
MHF series SMA adapter for receptacle high-cycle narrow-pitch wire L=200mm 90577-0200 -
MHF series SMA adapter for receptacle high-cycle narrow-pitch wire L=350mm 90577-0350 6571
MHF series SMA adapter for receptacle high-cycle narrow-pitch wire L=750mm 90577-0750 9769.8
MHF 4/4L/4L LK SMA adapter for receptacle high-cycle probe 90576-0001 1458.1
MHF series SMA adapter for receptacle high-cycle detachable base 90684-0001 15104.1
MHF 4/4L/4L LK SMA adapter for receptacle high-cycle detachable probe 90683-0001 1822.3
MHF 4L insertion/extraction tool [20572-001R-08][20565-001R-13] 90609-0001 600
MHF 4L insertion/extraction tool [20632-001R-37] 90873-0001 1020
MHF 4L insertion/extraction tweezer [20572-001R-08] 90616-0008 17320
MHF 4L insertion/extraction tweezer [20565-001R-13] 90615-0013 17730
MHF 4L insertion/extraction tweezer narrow-pitch 91493-0001 3560
MHF 4L type 06 semi-auto jig 90599-006 7500000
MHF 4L type 08 semi-auto jig 90599-008 7500000
MHF 4L type 13 semi-auto jig 90600-013 -
MHF 4L type 37 semi-auto jig 90703-037 -



SI Test Board with 2.92mm Adapter

Part Number Description Part Number Weight (mg) Image
SI Test Board for MHF 4L 91602-001B-001 18066

MHF_4L_SI_TB-859_Test_Board_(C)

Main Board

MHF_4L_SI_TB-859_THRU_Board_(C)
Thru Board

MHF 4L EOL PART NUMBERS

Part Number Descriptions EOL P/N Alternative I-PEX P/N Differences to alternative item
MHF 4L receptacle 20579-001E-01 20579-001E MOQ
