5G mmWave and Sub 6 GHz Solutions with Enhanced EMI Shielding Options
For more detailed information, contact Bruce Johnson, Account Executive, bruce.johnson@i-pex.com, 831-338-8665.
Or visit our Contact Us page.
MHF® 7S
Excellent EMC performance with fully-shielded design, ideal for 5G mmWave applications, VSWR 1.5 max at 15 GHz in small 2.0 x 2.0 mm footprint
-
Unique shielded design (ZenShield®) reduces unwanted EMI found in 5G mmWave applications
-
Small form factor with max VSWR 1.50
-
Industry-first stripline terminated signal pin inside receptacle ground contact
Mated Height (mm): 1.40 Max.
Frequency Range: Up to 15 GHz
Micro-Coaxial Cable (AWG): #32 (O.D. 1.13 mm)
For technical documentation on the MHF® 7S connector, click here.
NOVASTACK® 35-HDN
Ideal for 5G mmWave antenna module and devices, fully-shielded and narrow design, Power supply is available with Corson Alloy contact, 0.35 mm pitch, 0.7 mm height
-
Ideal for high frequency applications (5G mmWave, USB4 / Thunderbolt 3, etc.)
-
ZenShield® fully-shielded design, decreases EMC issue caused by 5G applications
-
Narrow depth and low height, fully shielded board-to-board connector
Contact Pitch (mm): 0.350
Mated Height (mm): 0.75 Max. (0.70 mm Nominal)
Available Pin Count: 10, 20, 30
Frequency Range: Up to 15 GHz
For technical documentation on the NOVASTACK® 35-HDN connector, click here.
MHF® 7
Micro RF connector for mmWave, ideal for 5G applications, VSWR 1.68 max at 45 GHz in small 2.1 x 2.0 mm footprint
-
Excellent electrical performance through 45 GHz
-
Controlled variation in characteristic impedance
-
MHF®7 Plug available micro-coax O.D. (AWG) : 1.13 mm (30
Mated Height (mm): 1.40 Max.
Frequency Range: Up to 45 GHz
Micro-Coaxial Cable (AWG): #30 (O.D. 1.13 mm)
For technical documentation on the MHF® 7 connector, click here.
